Amada CNC Turret Punch Press Model Pega 244

Specifications:

Maximum sheet size::                         39.37″ X 78.74″

Maximum axis travel::                        39.37″ X -Axis 41″ Y-Axis

Max. linear table speed::                     1968″ per min.

Punching accuracy::                            +/-0.004″ Hole to Hole

Maximum sheet thickness::                0.250″(mild steel)

Maximum material weight::               110 lb.

Repeatability::                                     +/-0.001″

Press capacity::                                   22 Tons

Press stroke::                                       1.575″

Maximum hole diameter::                  3.5″

Tool type::                                          Amada Thick Turret

Turret rotation speed::                        30 RPM

Turret capacity::                                  24 stations

Control::                                              Amada -Fanuc-P

Input method::                                    MDI, Floppy Disk Drive, RS-232

Operating modes::                              Automatic, MDI & Manual

Display modes::                                  Program Contents, Position Information, Program Check, Parameters, Tool Hit Counter, Self Diagnostics

Machine dimensions:                          157″ X 90″ X77″

Machine weight:                                 18,750 lbs
